WE’VE PUT THE GROOVE INTO BRICK CLADDING

UNIFIED BRICK CLADDING

MECHANICALLY SECURED AND SUPPORTED

Our patent-pending brick slip retention technology, seamlessly integrates our purpose-cut or extruded brick slips, steel support rails and mortar into a single, cohesive brick cladding finish.

  • Our purpose-made steel support rails, are fabricated to provide the mechanical retention of our purpose-made brick slips and additional key attachment into our purpose-made mortar.

    They are perforated to provide a true ventilated brick cladding, allowing our brick slips to breathe.

  • Purpose-made brick slips, cut from full bricks or through an extrusion process using natural kiln fired clay.

    Each brick slip is supplied with our groove attachment, to ensure every brick slip, even corners, is mechanically secured to our purpose-made steel support rails.

  • Our purpose-made mortar supplied in ready to mix 25kg bags provides two essential functions.

    It provides additional structure and strength by fusing our purpose-made steel support rails within it and setting around our mechanically secured purpose-made brick slips.

    Available in a range of colours, it also provides the aesthetic finish to create beautiful brick architecture.

BENEFITS

POWERED BY BRICKNOLOGY®

Reduced Weight

BRICKNOLOGY® weighs 45kg/m2 dry and 65kg/m2 wet making it over 50% lighter than traditional brickwork, reducing structural load on the building.

Design Patent Pending

Our patent-pending brick slip retention technology, is our unique innovation that ensures every brick slip is mechanically secured and supported as standard with BRICKNOLOGY®.

A1 Fire Rated

BRICKNOLOGY® purpose made steel rails, brick slips and mortar is classified as Euroclass A1 in accordance with EN 13501-1 and Delegated Regulation 2016/364.

Impact Resistance

BRICKNOLOGY® has withstood soft and hard body impact tests without any damage and therefore no risk.

Frost Resistance

Bricks classified as F2 Frost Resistance, in accordance with EN771-1, specification for clay masonry units are used with BRICKNOLOGY®.

Fast-Track Installation

BRICKNOLOGY® is straight forward to install, providing fast-track installation, which minimises time on site and significantly reduces construction overall.

Minimal Weather Dependency

Only the mortaring of BRICKNOLOGY® is solely dependent upon the weather. Our custom steel rails and brick slips can be installed whatever the weather, meaning less construction time being lost due to the inclement weather.

Any Brick Type

BRICKNOLOGY® is compatible with any brick type in UK, or other sizes, which we are able to provide a brick match, or a range of options to choose from.

No Height Limit

BRICKNOLOGY® is suitable for installation at any building height, subject to appropriate facade engineering calculations being carried out by qualified professionals.

Ventilated

BRICKNOLOGY® is a ventilated brick cladding. Our design allows any excess water absorbed by the natural clay brick  slips and mortar joints to rear drain through the ventilated cavity meaning no mould or water ingress being held on the face of the brick work.

Certified Testing

Our ambition is for BRICKNOLOGY® to become the most tested brick cladding product on the market. European Technical Assessment has already been achieved with proven results and test data to share.

Resistant to Wind Loading

BRICKNOLOGY® has been subjected to Wind pressure tests at +3000Pa and Wind Suction at -6600Pa with no visible damage.

BRICKNOLOGY® FINISHES

BRICK SLIPS

We partner with and supply an extensive range of brick slips from a multitude of market leading brick producers.

Our standard range provides over 350 different colours, finishes and textures to choose from.

With complete flexibility in mind, BRICKNOLOGY® has been designed to work with all brick types in UK dimensions (215 x 65mm).

To view our range of brick slips please click the button below, and should you have requirements for alternative brick sizes, please contact us.

WHERE IS BRICKNOLOGY® USED

APPLICATIONS

Choosing BRICKNOLOGY® opens the door to dynamic brick cladding architecture suitable for a whole spectrum of New Build, Refurbishment or Modular Offsite Construction projects. Its lightweight construction not only reduces the demand on foundations but also minimises the need for additional support structures, yielding significant cost savings, especially when compared to traditional brickwork.

BRICKNOLOGY® integrates with various architectural systems, making it an ideal choice for Facades, Wall Cladding, Balconies, and most applications where brick is used (excluding below DPC level).

What sets BRICKNOLOGY® apart is its exceptional efficiency, it is significantly faster to install, ensuring a fast-track approach to brick cladding construction.

 FREQUENTLY ASKED QUESTIONS

  • BRICKNOLOGY® is a mechanically secured brick slip cladding product.

  • As a cladding product 45kg/m2 when dry and up to 65kg/m2 when wet.

  • UK brick dimensions:

    Standard slips: 215 x 65mm

    Corner slips: 102 x 215 x 65mm

    BRICKNOLOGY® is also compatible with alternative brick sizes, please contact us to discuss any non-standard requirements further.

  • Minimum thickness of 25mm for cut brick slips and 19mm for extruded brick slips.
